Genesis Fugio 30
In stock
£1,999.99
Genesis Fugio 30
- Go anywhere and look good doing it
The Fugio 30 is here with a bold paint job and a specification to match. Built around our 6061 heat-treated aluminium Fugio frame and full carbon fork.
Running on the well-established Sram Apex 1x 11 drivetrain it?s the perfect partner for reliable 1x gravel riding, add in the Sram Apex hydraulic brakes and you have a serious package.
Don?t let the ?gravel? description deceive you though, this bike is capable of much more. For 2023 we?ve moved to a wider tyre from Vittoria that makes the bike even more capable.
Tubeless ready rims and tyres and ability to run up to 52c tyres on 650b or 40c on 700c.
Dirt, roots, rocks, you name it, the Fugio 30 is ready.
Press Review
★★★★
The Genesis Fugio 30 not only brings cool old-school mountain bike graphics and finishing to gravel, it also brings an old-school MTB sensibility with it. The Fugio 30 is all about the journey, the exploration, and riding terrain and trails beyond your comfort zone – and that of your bike. - Cyclingweekly
Brake Type :
Hydraulic Disc
Fork Material :
Carbon
Frame Material :
Alloy
Max Tyre Size :
700 x 40mm / 650b x 52mm
Brake Levers :
SRAM Apex Hydrualic 11-Speed
Intended Use :
Gravel
Brakes :
SRAM Apex Hydrualic Disc
Cassette Freewheel :
SRAM PG-1130 11-42T 11-Speed
Chain :
KMC X11
Chain Set :
Prowheel RPL-FD16AG 42T XS/SM = 170mm MD/LG = 172.5mm XL = 175mm
Fork :
Genesis Carbon Gravel Disc 1-1/8 - 1-1/2" Tapered"
Handlebars :
Genesis 31.8mm AL6061 T6 20 Deg Flare XS = 420mm SM/MD = 440mm LG = 460mm XL = 480mm
Headset :
Prestine F23A-2
Hubs :
KT QL-SL2F/KT QL-XD2R
Rear Derailleur :
SRAM Apex 1 Long Cage 11-Speed
Rims :
Shining DB-X25
Saddle :
Genesis Adventure
Seat Post :
Genesis Alloy 27.2 X 350mm
Shifters :
SRAM Apex 11-Speed
Stem :
Genesis Alloy 100 x 31.8mm -7 Deg
Tyres :
Vittoria Mezcal 27.5 x 2.1
Gender :
Mens, Womens
Wheel Size :
650b
150
152
154
156
158
160
162
164
166
168
170
172
174
176
178
180
182
184
186
188
190
192
194
196
198
200
Please be advised that this bicycle size chart is only a rough guide to help you select the correct frame size. We would always recommend visiting your local dealer to get measured and sized correctly, as although height is used, there are other factors which help determine the best frame size for you.
Geometry
| Frame Seat Tube | 550 |
|---|---|
| Frame Top Tube | 583 |
| Frame Reach | 395 |
| Frame Stack | 613 |
| Frame Head Tube | 185 |
| Frame Head Angle | 70.5 |
| Frame Seat Angle | 73 |
| Frame Chainstay | 425 |
| Frame BB Drop | 65 |
| Frame Wheel Base | 1062 |
| Fork Offset | 50 |
| Standover | 820 |
| Stem Length | 100 |
| Handle Bar Width | 460 |
| Frame Seat Tube | 530 |
| Frame Top Tube | 567 |
| Frame Reach | 385 |
| Frame Stack | 594 |
| Frame Head Tube | 165 |
| Frame Head Angle | 70.5 |
| Frame Seat Angle | 73 |
| Frame Chainstay | 425 |
| Frame BB Drop | 65 |
| Frame Wheel Base | 1045 |
| Fork Offset | 50 |
| Standover | 801 |
| Stem Length | 100 |
| Handle Bar Width | 440 |
| Frame Seat Tube | 500 |
| Frame Top Tube | 551 |
| Frame Reach | 375 |
| Frame Stack | 575 |
| Frame Head Tube | 145 |
| Frame Head Angle | 70.5 |
| Frame Seat Angle | 73 |
| Frame Chainstay | 425 |
| Frame BB Drop | 65 |
| Frame Wheel Base | 1029 |
| Fork Offset | 50 |
| Standover | 779 |
| Stem Length | 100 |
| Handle Bar Width | 440 |
| Frame Seat Tube | 580 |
| Frame Top Tube | 598 |
| Frame Reach | 405 |
| Frame Stack | 631 |
| Frame Head Tube | 205 |
| Frame Head Angle | 70.5 |
| Frame Seat Angle | 73 |
| Frame Chainstay | 425 |
| Frame BB Drop | 65 |
| Frame Wheel Base | 1077 |
| Fork Offset | 50 |
| Standover | 843 |
| Stem Length | 100 |
| Handle Bar Width | 480 |
| Frame Seat Tube | 470 |
| Frame Top Tube | 535 |
| Frame Reach | 365 |
| Frame Stack | 556 |
| Frame Head Tube | 125 |
| Frame Head Angle | 70.5 |
| Frame Seat Angle | 73 |
| Frame Chainstay | 425 |
| Frame BB Drop | 65 |
| Frame Wheel Base | 1012 |
| Fork Offset | 50 |
| Standover | 756 |
| Stem Length | 100 |
| Handle Bar Width | 420 |
