Genesis Zero SL Team Frameset 2019

£1,599.99
SKU:
VARGNBC1
In stock
Loading...

Select Local Store
In stock
Add to Wish List Save for later

Product Details

Genesis Zero SL Team Frameset 2019 | Road Bike Frames | Freewheel

Zero SL Frameset

Moving up the ranks in the league and chasing that 1st cat or elite ranking? Here is the frame to get you there.

The Zero SL is the exact same frame our factory riders use down to the last detail or even decal, painted up in the team colours the Zero SL is made from our highest grade 30/40T modulus carbon fibre which allows us to fine tune it down to the nth degree and get each and every last bit of performance out of the frame. Ready to take a mechanical or Di2 set up all internally routed the UCI approved Zero SL frame is screaming out to be built up in to formidable race weapon.

Tech Highlights

30/40T MODULUS CARBON

CARBON FAME

GENESIS CARBON SL ROAD RACE DISC

FORK

700c

WHEEL SIZE

TAPERED HEADTUBE

HEADTUBE

Di2 INTERNAL ROUTING

ROUTING

Features

Powered by Shimano Steps

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nam dignissim elementum auctor.

Weatherproof System

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nam dignissim elementum auctor.

3 Assist Modes

Donec pellentesque maximus leo vel egestas. Pellentesque eget porta dui, eget lobortis orci.

4 Hour Charge Time

Illa. Phasellus non ultricies ex. Aenean libero nunc, egestas auctor nisl vel, lobortis rutrum orci.

Geometry

NameXSSMLXL
Seat Tube480mm510mm540mm570mm600mm
Top Tube525mm545mm565mm585mm600mm
Frame Reach375mm385mm390mm400mm405mm
Frame Stack530mm545mm575mm602mm625mm
Head Tube130mm145mm175mm205mm230mm
Head Angle72°73°73.5°73.5°74°
Seat Angle74°73.5°73°72.5°72.5°
Chain Stay405mm407mm407mm410mm410mm
BB Drop68mm68mm68mm68mm68mm
Wheelbase974mm977mm1003mm1003mm1012mm
Fork Offset45mm45mm45mm45mm45mm
Fork Trail62mm55mm52mm51mm51mm
Standover740mm750mm780mm810mm840mm

Delivery Options

Click & Reserve

Reserve & Collect FREE

from your local bike shop tomorrow from 2pm

Find out more
Uk Delivery

UK and Ireland Delivery

UK Standard 2-3 working days £4.95, FREE on orders over £50

UK Next Day (Only available Mon-Thurs before 2pm) £6.95

Find out more

`

Specification

Frame 30/40T Modulus Carbon Road Race Disc w/ Tapered Headtube & Fully Internal Cable Routing
Rear Shock N/A
Fork Genesis Carbon SL Road Race w/ 1.5" - 1-1/8" Tapered Steerer
Headset Prestine PT-1860C- 616
Shifters N/A
Rear Derailleur N/A
Front Derailleur Braze-on (not incl.)
Chainset N/A
Bottom Bracket BB86 Press-fit (not incl.)
Chain N/A
Cassette / Freewheel N/A
Rims N/A
Hubs N/A
Spokes N/A
Tyres N/A
Brakes N/A
Brake levers N/A
Handlebars N/A
Grips / Tape N/A
Stem N/A (not incl.)
Saddle N/A
Seatpost 27.2mm (not incl.)
Pedals N/A
Extras
Weight 1.32 inc Seat Collar/Headset
